Max-Fire (Ultra-Spark 50) GM LS Truck Spark Plug Wire Set

$80.95

Edelbrock Max-Fire High Performance Spark Plug Wires without Heat Shields, 8.5mm red silicone outer jacket, Kevlar inner core, 50 ohms per foot resistance, excellent EMI/RFI suppresion

In stock

SKU

22717

Details

Edelbrock Max-Fire LS Ignition Wire Kits #22717 is a preassembled set of eight spark plug wires for General Motors LS engines. These wires are manufactured using high-quality materials to ensure the best performance possible with a heavy-duty 8.5mm red silicone outer jacket to protect the spiral-wound Kevlar inner core from heat, moisture and chemicals. This direct-fit wire set delivers maximum voltage with extremely high EMI/RFI suppression with 50 ohms per foot of resistance. This kit is ideal for LS builds that demand a high-performance ignition system upgrade with a precision fit and a show-quality appearance. See application chart for engine- or vehicle-specific Max-Fire kits.

PRODUCT SPECS

More Information
Manufacturer	Edelbrock
Application	Application Specific
UPC	00085347227174
Availability Note	Available to Order
Warranty	12 Months
Insulation Color	White
Wire Separators Included	No
Coil End Boot Color	Black
Spark Plug End Boot Color	Black
Spark Plug Wire Resistance	50 Ohms
Core Material	Magnetic Kevlar Core
Insulation Outside Diameter	0.23 in
Insulation Material	EPDM
Noise Suppression Type	Yes
Spark Plug Boot Material	Compact Silicone
Emissions Code
Features and Benefits	• Complete preassembled set of LS ignition wires that require no cutting or splicing • Red 8.5mm outer silicone jacket • Excellent protection from heat, chemicals and moisture • 50 ohms per foot of resistance • Excellent EMI/RFI suppression
Hazardous Materials Warning	WARNING: This product can expose you to Chromium, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Installation Notes	Inspect your spark plug wires regularly! Spark plug wires require periodic changing and should be replaced if damaged or if they show signs of wear. If you want to keep the performance of your engine at the optimal level, we recommend you replace your spark plug wires at the same time you replace your spark plugs. Fouled, damaged, or worn out spark plugs can lead to a variety of engine problems, such as misfires, hard starts, increased emissions, poor fuel economy and reduce acceleration. For most vehicles, you should replace your spark plugs every 30,000 miles.
Outside Diameter	8.5 mm
Resistance	50 Ohms
Spark Plug End Boot Degree	45 deg
Spark Plug End Boot Quantity Straight	8
Spark Plug End Terminal Type	LS
Universal Or Specific Fit	Specific
Wire 1 Length	12.5 in
Wire 2 Length	12.5 in
Wire 3 Length	12.5 in
Wire 4 Length	12.5 in
Wire 5 Length	12.5 in
Wire 6 Length	12.5 in
Wire 7 Length	12.5 in
Wire 8 Length	13.0 in
