E-CNC Gen III LS Chevy Cylinder Head Hydraulic Roller Camshaft

$1,792.95

Edelbrock part #79949 E-CNC Small Block Chevy GEN 3 & 4 LS cylinder heads were designed for 1997 & later GEN 3 & 4 LS1/LS2 Chevy engines including 4.8L, 5.3L, 5.7L & 6.0L.

TEMPORARILY OUT OF STOCK

SKU

79949

Details

The Edelbrock 79949 E-CNC Small Block Chevy GEN 3 & 4 LS cylinder heads were designed for 1997 & later GEN 3 & 4 LS1/LS2 Chevy engines including 4.8L, 5.3L, 5.7L & 6.0L. All E-CNC Cylinder Heads feature fully CNC'd intake ports, combustion chambers and exhaust ports for improved air-flow. Dyno tests proved these heads are capable of 457 hp & 438 ft-lbs. of torque. High-quality conical beehive springs are secured with steel retainers and valve locks for performance up to .600" valve lift. Match with any one of Edelbrock's LS series intake manifolds and camshafts for a dyno-proven performance combination. Rocker bolt kit #8597 includes 8 rocker bolts that are shorter than stock to prevent the bolts from protruding into the intake ports. E-CNC 215 head is 50-state street legal.

PRODUCT SPECS

More Information
Part Type	Engine Cylinder Head
Manufacturer	Edelbrock
Engine Manufacturer	Chevrolet
Engine Family Name	LS Gen III, LS Gen IV
Engine Size	293 (4.8L), 325 (5.3L), 346 (5.7L), 364 (6.0L)
Application	Application Specific
UPC	085347799497
Series	E-CNC
Material	Aluminum
Intake Valve Diameter	2.02 in
Valve Angle	15 Degree
Intake Runner Volume	215 cc
Grade Type	Performance
Quantity	Sold Individually
Camshaft Type	Hydraulic Roller
Horsepower	400-500 HP
Warranty	12 Months
Seat Angle	Exhaust 45 deg/Intake 45 deg
Emissions Code	EO Number: D-215-70
Application Summary	Chevrolet:Small-Block Gen III LS1:346 (5.7L);Chevrolet:Small-Block Gen III LS2:364 (6.0L);Chevrolet:Small-Block Gen IV LS2:364 (6.0L)
Hazardous Materials Warning	WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Pushrod Diameter	0.3125 (5/16) in
Valve Spring Diameter	1.30 in
Valve Spring Maximum Lift	0.680 in
Valve Stem Diameter	0.314961 in
