XFI Sportsman EFI (Multi-Port) Engine Control System

Designed for muscle car, late model street and sportsman drag racing engines, along with boosted and individual runner throttle body applications, the FAST XFI Sportsman Engine Control System is a bank-to-bank, fully software-tunable EFI setup. It requires a laptop for tuning and uses proven FAST C-Com software, which comes packaged along with the necessary USB connectivity cable. The system offers both load-indexed Speed Density or Alpha-N fuel strategies; most users will use Speed Density but the Alpha-N option is specifically added to serve Sportsman drag racers looking for absolute consistency and Data Logging and Nitrous Timing Retard and Boost Capable.

The FAST XFI Sportsman System features full tables to monitor fueling, acceleration fuel, timing and air/fuel targets. A user-configurable auxiliary input channel and full-function data logging are also included. It'supports both naturally aspirated and boosted applications up to 5 bar, is compatible with wet nitrous and has nitrous timing retard control. Built-in CAN network support for the EZ-TCU, EZ-LS, XIM and eDash means users can easily plug-and-play those components with the included CAN network and wire. The FAST XFI Sportsman Engine Control System also features a Bosch wide-band 02 sensor, utilizes built-in diagnostic LEDs, a water-resistant ECU enclosure and includes a premium, mesh-type wire loom multi-port harness and Multi-Port EFI or Use EZ-EFI Throttle Body

Compatible with return-style and returnless fuel systems, XFI Sportsman is designed for use with high-impedance injectors, and works with a variety of multi-port systems or either generation of the FAST EZ-EFI throttle body. XFI Sportsman is conveniently configurable for electronic timing control with FAST distributors and crank triggers, EZ-LS and XIM, or timing can be set with a standard carb-type distributor and the included tach adapter. The RPM/tach signal from an aftermarket CD ignition box is also a timing control option.

Information Summary - Includes ECU, Wiring Harness for Wide-Band O2 Sensor and Electronic Fuel Pressure Kit. Works with high-impedance injectors and also with EZ-EFI or EZ-EFI 2.0 throttle body. Utilizes Speed Density and Alpha-N fuel strategies; Alpha-N included just for Sportsman drag racers. Utilizes FAST C-COM software and ndash; Comes packaged along with necessary USB connectivity cable. For muscle car, late model, boosted, individual runner throttle body and Sportsman drag racing engines. Supports N/A and boosted applications up to 5 bar, works with nitrous and features timing retard control. CAN network support for EZ-TCU, EZ-LS, XIM and eDash with included plug and play CAN wire. Works with high-impedance injectors and also with EZ-EFI or EZ-EFI 2.0 throttle body. Includes and self tuning strategy that EZ-EFI offers but can be user disabled/enabled.
