Victor Series Water Pump for Ford 5.0 V8 Reverse Rotation, Black Finish
$369.95
Edelbrock Victor Series Water Pump for Ford 5.0L 1986-93 Reverse Rotation, Black, Ideal To Prevent Overheating In Street Rods And Street Machines
In stock
SKU
88403
Edelbrock #88403 Water Pump Ford 5.0l 1986-93 reverse rotation with a black finish is ideal to prevent overheating in street rods and street machines. Using state-of-the-art racing technology, Edelbrock has designed these "super cooling" Water Pumps to provide maximum flow, maximum pressure and equal distribution to both sides of the block within 1%. This high performance pump flows in only one direction for optimum efficiency. The casting's computer-designed internal passages and precision powdered metal impeller produce the maximum flow rate possible.
| Part Type | Engine Water Pump |
|---|---|
| Manufacturer | Edelbrock |
| Engine Manufacturer | Ford |
| Engine Family Name | Small-Block Windsor |
| Engine Size | 302 (5.0L) |
| Application | Application Specific |
| UPC | 085347884032 |
| Series | Victor |
| Grade Type | Performance |
| Gasket Or Seal Included | Yes |
| Casting Number | 8840 |
| Water Pump Drive Type | Serpentine Belt |
| Pump Flow | High Volume |
| Water Pump Inlet Diameter | 1.78 in |
| Water Pump Rotation | Counterclockwise |
| Water Pump Style | Standard |
| Pilot Shaft Diameter | 0.625 in |
| Pulley Included | No |
| Housing Material | Aluminum |
| Outlet Quantity | 1 |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 10 |
| Hub Height | 5.75 in |
| Hub Hole Quantity | 6 |
| Installation Warnings | Yes |
| Impeller Material | Powdered Metal |
| Impeller Rotation | Reverse |
| Impeller Vane Quantity | 6 |
| Includes Back Housing | Yes |
| Related Cooling Fan Components | No |
| Fan Clutch Included | No |
| Thermostat And Housing Included | No |
| Warranty | 12 Months |
| Color | Black |
| Emissions Code | N/A |
| Features and Benefits | Heavy-duty, 0.75" internal ball/roller bearing used to withstand higher torsional loads at high rpm. Equal coolant distribution to both sides of the block within 1% for better cooling efficiency. Heavy-duty seal used for leak-proof operation and long life. |
| Application Summary | Ford:V8:302 (5.0L) |
| Hazardous Materials Warning |
 WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
