Water Pump for Gen IV LS Engine 2009-16
$569.95
Edelbrock #8894 Water Pump Gen IV LS Engine 2009-16 Ideal To Prevent Overheating In Street Rods And Street Machines
In stock
SKU
8894
Edelbrock #8894 Water Pump for 2009-16 GEN IV LS engines (except Cadillac CTS-V) are ideal to prevent overheating in street rods and street machines, as well as in tow rigs and motorhomes. Using state-of-the-art racing technology, Edelbrock has designed these "super cooling" Water Pumps to provide maximum flow, maximum pressure and equal distribution to both sides of the block within 1%. Available for most popular applications, these high performance pumps flow in only one direction for optimum efficiency. The casting's computer-designed internal passages and precision powdered metal impeller produce the maximum flow rate possible.
| Part Type | Engine Water Pump |
|---|---|
| Manufacturer | Edelbrock |
| Engine Manufacturer | Chevrolet |
| Engine Family Name | LS Gen III, LS Gen IV |
| Engine Size | 376 (6.2L) |
| Application | Application Specific |
| UPC | 085347088942 |
| Series | Victor |
| Grade Type | Performance |
| Gasket Or Seal Included | No |
| Casting Number | 8894 |
| Water Pump Drive Type | Serpentine Belt |
| Pump Flow | High Volume |
| Water Pump Rotation | Counterclockwise |
| Water Pump Style | Standard |
| Pilot Shaft Diameter | 0.75 in |
| Pulley Included | No |
| Housing Material | Aluminum |
| Outlet Quantity | 1 |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 6 |
| Hub Height | 5.31 in |
| Hub Hole Quantity | 6 |
| Installation Warnings | Yes |
| Impeller Material | Powdered Metal |
| Impeller Rotation | Reverse |
| Impeller Vane Quantity | 6 |
| Includes Back Housing | Yes |
| Related Cooling Fan Components | No |
| Fan Clutch Included | No |
| Thermostat And Housing Included | No |
| Warranty | 12 Months |
| Color | Natural |
| Emissions Code | N/A |
| Features and Benefits | Heavy-duty, 0.75" internal ball/roller bearing used to withstand higher torsional loads at high rpm. Equal coolant distribution to both sides of the block within 1% for better cooling efficiency. Heavy-duty seal used for leak-proof operation and long life. |
| Application Summary | Chevrolet:Gen IV L76:364 (6.0L);Chevrolet:Gen IV LS3:376 (6.2L);Chevrolet:Gen IV LS7:427 (7.0L);Chevrolet:Gen IV LSA:376 (6.2L) |
| Hazardous Materials Warning |
 WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
