Victor Jr. Big Block Chevy 454-O EFI Intake Manifold

Edelbrock Victor Jr. 454-O EFI Intake Manifold For Chevrolet 396-502 Big-Block V8
In stock
The Edelbrock Victor Jr. 454-O #29045 EFI intake manifold is designed for competition 396-502 big-block Chevys. This Edelbrock Single-plane, high-rise EFI intake is designed for maximum race-winning power at higher engine speeds. Edelbrock engineers work in conjunction with leading engine builders from all forms of competition to design manifolds compatible with the latest technology. The Edelbrock Victor Jr. 454-O #29045 EFI intake manifold fits large oval-port heads (1975 and earlier). Features include extended runner dividers, smaller plenum chambers and unique runner design for better 60 foot times and max power from 3500 to 7500 rpm. This manifold is especially suited to 502 c.i.d. and smaller competition engines. The Edelbrock Victor Jr. 454-O #29045 also features a natural aluminum finish for a classic look. For the ultimate "Made in USA" quality, every Edelbrock intake manifold is cast and machined in the USA.

Installation Notes:
• Recommended intake gasket: Edelbrock #7203
• Throttle Body Recommendations: Use #3878 4V series or #3849 EFI elbow and #3869 90mm throttle body.
• Match with Edelbrock fuel rail kit #3633
• Manifold height: A-5.90" & B-5.90"
More Information
Manufacturer Edelbrock
Application Application Specific
UPC 00085347290451
Series Victor
Grade Type Performance
Gasket Or Seal Included No
Vehicle Model Chevrolet
Availability Note Available to Order
Warranty 12 Months
RPM Range 3500-7500 RPM
Emissions Code
Hazardous Materials Warning WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit
Color Satin
Finish Satin
Material Aluminum
Rear Maximum Height 5.960 in
Single Or Dual Plane Type Single
