Victor Jr. 351W Intake Manifold Small-Block Ford

$499.95

Edelbrock Victor Jr. 351W (9.5" deck) Intake Manifold for Ford 351-427 Small-Block Windsor V8

In stock

SKU

2981

Details

Edelbrock Part # 2981 Victor Jr. 351W (9.5芒鈧聺 deck) intake manifold is designed for competition 351 Windsor Ford V8's from 1969 and later with the following heads: Edelbrock Performer RPM heads #60259, Victor Jr. heads #77169, Victor heads #77219 or similar heads. This intake manifold fits SVO blocks with a 9.5" deck height. Ideal for both oval track and drag racing engines operating between 3500 and 7500 rpm. Runners have a 2.70 square-inch cross sectional area. The Edelbrock Victor Jr. is a single-plane, high-rise intake designed for maximum race-winning power at higher engine speeds.

PRODUCT SPECS

More Information
Part Type	Engine Intake Manifold
Manufacturer	Edelbrock
Engine Manufacturer	Ford
Engine Family Name	Small-Block Windsor
Engine Size	351 (5.8L)
Application	Application Specific
UPC	085347029815
Series	Victor
Material	Aluminum
Finish	Satin
RPM Operating Range	3500-7500 RPM
Gasket Or Seal Included	No
Vehicle Model	Ford
Warranty	12 Months
Emissions Code
Application Summary	Ford:Small-Block Windsor:351 (5.8L)
Hazardous Materials Warning	WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Installation Notes	Recommended intake gasket: Edelbrock # 7220 or Fel-Pro # 1262 Manifold height: A-5.75", B-5.75" Cab recommendations: Any size or type of carburetor class allows Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant # 1076, DO NOT USE END SEALS GASKETS. Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
Rear Maximum Height	5.750 in
Single Or Dual Plane Type	Single
