Torker Holden 253-308 Intake Manifold

The Edelbrock Torker 308 #2790 intake manifold is designed for Holden 253-304-308 c.i.d. V8 engines with Red motor cylinder heads only (with single bolt in center of manifold), will not fit on Blue/Black cylinder head engines. The Torker 308 intake manifold is a single-plane design and is recommended for street high performance and race engines operating between the 2500 to 6500 rpm range where low-end torque is not required. Accepts square-bore carbs only. The Edelbrock Torker 308 #2790 also features a natural aluminum finish for a classic look. For the ultimate "Made in USA" quality, every Edelbrock intake manifold is cast and machined in the USA.

Installation Notes:
• Do not use competition style intake gaskets for this street manifold. Due to material deterioration over time, internal leakage of vacuum, oil, and coolant may occur.
• Recommended intake gasket: OEM equivalent.
• Manifold height: A-2.95”, B-4.50”
• Carb pad height: 3.73”
• Port exit dimensions: 1.03” x 1.88”
• Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS.
• Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
