Super Victor EFI Tall Deck Big Block Chevy Intake Manifold

$679.95

Edelbrock Super Victor EFI Tall Deck Intake Manifold For Chevrolet 500+ Ci. Big-Block V8

TEMPORARILY OUT OF STOCK

SKU

29165

Details

Edelbrock Part # 29165 Super Victor BBC #29165 Tall-Deck EFI intake manifold is designed for Chevy big-blocks with rectangular port cylinder heads. This single-plane design is ideal for 500+ cubic-inches or any big-block drag race engine with high air flow requirements. In dyno testing, Super Victor #29165 Tall-Deck EFI outperformed the competition out-of-the-box with just a port match and minor blending of critical surfaces.

PRODUCT SPECS

More Information
Part Type	Engine Intake Manifold
Manufacturer	Edelbrock
Engine Manufacturer	Chevrolet
Engine Family Name	Big-Block Gen V, Big-Block Mark IV, Big-Block Race
Engine Size	454 (7.4L), 502 (8.2L), Race
Application	Application Specific
UPC	085347291656
Series	Victor
Material	Aluminum
Finish	Satin
RPM Operating Range	3500-8500 RPM
Gasket Or Seal Included	No
Vehicle Model	Chevrolet
Warranty	12 Months
Emissions Code
Application Summary	Chevrolet:Big-Block Mark IV:396 (6.6L)/402 (6.6L)/427 (7.0L)/454 (7.4L)/502 (8.2L)
Hazardous Materials Warning	WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Installation Notes	Recommended intake gasket: Edelbrock # 7208, Fel-Pro # 1275 Manifold height: A-6.20", B-6.20" Throttle body recommendations: Edelbrock # 3879 4500 style or # 3814 EFI elbow and # 3869 90mm throttle body. Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant # 1076, DO NOT USE END SEALS GASKETS. Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
Rear Maximum Height	6.950 in
Single Or Dual Plane Type	Single
