Super Victor Chrysler 440 Max Wedge Intake Manifold for 4500 Series Carb

$597.95
Edelbrock Super Victor 440 Max Wedge Intake Manifold with 4500 Series Carb for Chrysler 413-426-440 Big-Block V8
In stock
SKU
2893
The Edelbrock Super Victor 440 Max Wedge #2893 intake manifold is designed for 413-440-500+ RB with Max Wedge heads and 4500 Series carburetors. For competition and high-rpm 413-426-440 c.i.d. Chrysler V8's, the Super Victor 440 #2893 has an all-new runner design that delivers maximum power from 3500 to 8000 rpm in drag race applications. Super Victor 440 Max Wedge #2893 intake manifold is designed to fit 1962-64 Max Wedge heads or the Edelbrock Victor Max Wedge cylinder heads #77939 and #77949 for maximum performance. The manifold port exits are CNC machined to 1.30" x 2.58". The #7798 valley cover is required when used with Edelbrock Victor Series cylinder heads. Whether you're building a daily driver, ultra high-performance street machine or race car, an Edelbrock intake manifold will provide the power right where you want it. The Edelbrock Super Victor 440 Max Wedge #2893 also features a natural aluminum finish for a classic look. For the ultimate "Made in USA" quality, every Edelbrock intake manifold is cast and machined in the USA.

Installation Notes:
• Mopar Performance P/N P5249643, Fel-Pro #1218 or equivalent 2.63" x 1.34" for an area of 3.52 sq. inches. Custom gasket trimming is needed if larger area is desired.
• Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS.
• Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
More Information
Manufacturer Edelbrock
Application Application Specific
UPC 00085347028931
Series Victor
Material Aluminum
Grade Type Performance
Gasket Or Seal Included No
Vehicle Model Chrysler
Availability Note Available to Order
Warranty 12 Months
RPM Range 3500-8000 RPM
Emissions Code
Hazardous Materials Warning WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Color Satin
Finish Satin
Rear Maximum Height 6.400 in
Single Or Dual Plane Type Single
