Pro-Flo XT Small Block Chevy LS2 EFI Intake Manifold

Edelbrock Pro-Flo XT LS2 EFI Intake Manifold For Chevrolet LS Gen III
In stock
The Edelbrock Pro-Flo XT LS2 #7140 EFI intake manifold is engineered with a large plenum and tapered runners to deliver maximum horsepower and broad torque band throughout the rpm range (1500-7000 rpm). Features a 90mm throttle bore opening and 2.75" port exit height. This manifold produced 30 more horsepower over a stock LS6 manifold at 6500 rpm. The Edelbrock Pro-Flo XT LS2 #7140 intake manifold accepts GM OEM 90mm or Edelbrock #3869 throttle bodies. Compatible with LS1 Fuel Rail Kit #3629 (sold separately), which features -6 AN inlet and outlet. The Edelbrock Pro-Flo XT LS2 #7140 also features a natural aluminum finish for a classic look.

Installation Notes:
• Recommended intake gasket: LS1/LS6 style individual port o-ring seals or Edelbrock #7386
• Port exit dimensions: 1.04”x 2.74”
• Manifold Dimensions: A-10.20", B-10.00", C-16.90", D-3.2", E-15-degree
• The throttle body centerline is located 6.75” above the valley plate and 2.5” forward of the first manifold hold-down bolt
• Throttle bracket included
• A bracket for mounting an LS1 style MAP sensor is included
• Edelbrock #3629 LS1 XT Fuel Rail kit including provisions for either Pico or standard height injectors (available separately)
• Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS.
• Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
More Information
Manufacturer Edelbrock
Application Application Specific
UPC 00085347071401
Series Pro-Flo XT
Grade Type Performance
Gasket Or Seal Included No
Vehicle Model Chevrolet
Availability Note Available to Order
Warranty 12 Months
RPM Range 1500-7000 RPM
Emissions Code
Hazardous Materials Warning WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit
Color Satin
Finish Satin
Material Aluminum
Rear Maximum Height 10.000 in
Single Or Dual Plane Type Single
