Pro-Flo XT Chrysler Big Block RB EFI Intake Manifold

$679.95

Edelbrock Pro-Flo XT EFI Intake Manifold for Chrysler 413-426-440 Big-Block V8

In stock

SKU

7144

Details

The Pro-Flo XT Chrysler 440 #7144 EFI intake manifold is engineered with a large plenum and long tapered runners to deliver maximum horsepower and broad torque band throughout the rpm range 1500-7000 rpm. Features include a 90mm throttle bore opening. This manifold produced 20 more horsepower over our #35090 manifold at 5500 rpm. Accepts Victor LS Series throttle body #3970 or #39703. Compatible with B/B Chrysler XT Fuel Rail Kit #3644 (sold separately).

PRODUCT SPECS

More Information
Part Type	Engine Intake Manifold
Manufacturer	Edelbrock
Engine Manufacturer	Chrysler / Dodge / Plymouth
Engine Family Name	RB Engine
Engine Size	413 (6.8L), 426 (7.0L), 440 (7.2L)
Application	Application Specific
UPC	085347071449
Series	Pro-Flo XT
Material	Aluminum
Finish	Satin
RPM Operating Range	1500-7000 RPM
Gasket Or Seal Included	No
Vehicle Model	Chrysler
Warranty	12 Months
Emissions Code
Application Summary	Chrysler:Big-Block RB Series:413 (6.8L)/426 (7.0L)/440 (7.2L)
Hazardous Materials Warning	WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Installation Notes	Recommended gasket: Edelbrock # 7255. Throttle body recommendations: Edelbrock # 3970, # 39703 Manifold Dimensions: A-9.70", B-9.60", C-15.90", D-4.0", E-15° Port exit dimensions: 1.12" x 2.12" Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant # 1076, DO NOT USE END SEALS GASKETS. Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
Rear Maximum Height	9.600 in
Single Or Dual Plane Type	Single
