Dual-Quad Hemi Gen II EFI Intake Manifold

was $741.95 Special Price $667.76

Edelbrock Dual-Quad Chrysler Gen II 426-572 HEMI EFI Intake Manifold

In stock

SKU

75245

Details

Edelbrock Part # 75245 Dual-Quad HEMI EFI intake manifold is intended for use with Mopar Gen II (1964-71) 426-572 HEMI engines operating in the 2,500 to 6,500+ range. This new intake manifold is a single-plane Air-Gap design with a dual square-bore 4150 style throttle body pad. Throttle body spacing and height are the same as Mopar Performance dual-quad #P5153737, making it a direct bolt-on to all vehicles with a shaker hood. The Dual-Quad HEMI is compatible with factory style cylinder heads, but optimized for use with Edelbrock Victor Jr. HEMI cylinder heads. Requires Edelbrock Coil Bracket #8079 for use with OE style coils.

PRODUCT SPECS

More Information
Manufacturer	Edelbrock
Application	Application Specific
UPC	00085347752454
Series	Dual-Quad/Multi Carb
Material	Aluminum
Gasket Or Seal Included	No
Vehicle Model	Chrysler
Availability Note	Available to Order
Warranty	12 Months
RPM Range	2500-6500 RPM
Emissions Code
Hazardous Materials Warning	WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Installation Notes	Recommended intake gasket: Edelbrock #7278 Manifold height: A-4.68", B-5.51" Carb pad height: 5.10" Port exit dimensions: 1.80" x 1.98" Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS. Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
Finish	Satin
Rear Maximum Height	5.510 in
Single Or Dual Plane Type	Single
